TWM-SP001

Horizontal Brushless Motor Slot Insulation Paper Inserting Machine

TWM-SP001 is a horizontal brushless motor slot insulation paper inserting machine built by Teamwork Automation in Taichung, Taiwan. Supplied as a standalone machine or integrated into a complete production line.

Category: Brushless Motor Equipment
Process stage: Brushless Motor Equipment
Motor types: Brushless (BLDC) motors

Tags Slot liner insertion Brushless (BLDC) motor Stator Standalone machine

Request a quotation Book a video call

Product description

What this machine does

Automatically feeds insulation paper from a reel, cuts it to slot length, forms the U-shape, and inserts one liner into every stator slot in a single pass.
Horizontal orientation designed for larger BLDC stator diameters and heavier stacks that are awkward to handle vertically.
Servo-driven forming and insertion head with programmable stroke, engineered to keep the liner square in the slot without folding or tearing.
Configurable for stator OD, stack height, slot count and paper thickness; tooling change is a rapid module swap.
Designed for integration into a BLDC stator production line ahead of the winding station.

Specifications

What this machine is rated for

Workpiece: brushless (BLDC) motor stators, horizontal loading
Material: pre-cut sheet or reel-fed insulation paper
Operations: feed, cut, form (U-shape), insert
Cycle: one insertion pass covers all slots
Automation: standalone or integrated with upstream/downstream stations

Capabilities shown are typical. Values outside this range can be quoted on request.
